NVIDIA GeForce RTX 5070 Ti
5 laptops with NVIDIA GeForce RTX 5070 Ti in comparion
Core Information
GPU Name
GB205
GPU Variant
GB205
Model Series
NVIDIA GeForce RTX 50
Release Date
02.01.2025
GPU Specifications
GPU Architecture
Blackwell
Base Clock
847 MHz
Boost Clock
2220 MHz
Integrated GPU
No
Compute Units
Render Output Units
80
Texture Mapping Units
184
Shader Units
5888
Tensor Cores
184
SM Count
46
Hardware Ray Tracing
Yes
Ray Tracing Units
46
Memory
Memory Type
GDDR7
Memory Clock
1750 MHz
Effective Memory Data Rate
28 Gbps
Memory Bandwidth
672 GB/s
System-Dependent Memory Bandwidth
No
Memory Size
12 GB
Memory Interface
192 Bit
Shared Memory
No
Dedicated Graphics Memory
Yes
Unified Memory
No
Cache
L2 Cache
48 MB
Theoretical Performance
Pixel Fill Rate
115.8 GPixel/s
Texture Fill Rate
266.2 GTexel/s
FP16 Compute Performance
17.04 TFLOPS
FP16 Ratio
1:1
FP32 Compute Performance
17.04 TFLOPS
FP64 Compute Performance
266.2 GFLOPS
FP64 Ratio
1:64
Manufacturing
Official Process Name
TSMC 4N
Foundry
TSMC
Process Node
5 nm
Chip Specifications
Die Area
263 mm²
Transistors
31100 Millionen
Transistor Density
118.3 M / mm²
Power Consumption
Minimum Power Consumption
60 Watt
Maximum Power Consumption
115 Watt
Supported Standards
DirectX
12.2
OpenGL
4.6
OpenCL
3.0
Vulkan
1.4
CUDA
12.8
Shader Model
6.9
Connectivity
Host Interface
PCIe 5.0 x16
