NVIDIA GeForce RTX 5070

NVIDIA GeForce RTX 5070

3 laptops with NVIDIA GeForce RTX 5070 in comparion

Core Information
GPU Name
GB206
GPU Variant
GB206
Model Series
NVIDIA GeForce RTX 50
GPU Specifications
GPU Architecture
Blackwell
Base Clock
907 MHz
Boost Clock
1425 MHz
Integrated GPU
No
MXM Module
No
Compute Units
Render Output Units
48
Texture Mapping Units
144
Shader Units
4608
Tensor Cores
144
SM Count
36
Hardware Ray Tracing
Yes
Ray Tracing Units
36
Memory
Memory Type
GDDR7
Memory Clock
1500 MHz
Effective Memory Data Rate
24 Gbps
Memory Bandwidth
384 GB/s
System-Dependent Memory Bandwidth
No
Memory Size
8 GB
Memory Interface
128 Bit
Shared Memory
No
Dedicated Graphics Memory
Yes
Unified Memory
No
Cache
L2 Cache
32 MB
Theoretical Performance
Pixel Fill Rate
68.4 GPixel/s
Texture Fill Rate
205.2 GTexel/s
FP16 Compute Performance
13.13 TFLOPS
FP16 Ratio
1:1
FP32 Compute Performance
13.13 TFLOPS
FP64 Compute Performance
205.2 GFLOPS
FP64 Ratio
1:64
Manufacturing
Foundry
TSMC
Process Node
5 nm
Chip Specifications
Die Area
181 mm²
Transistors
21900 Millionen
Transistor Density
121 M / mm²
Chip Integration
Monolithic
Power Consumption
Minimum Power Consumption
50 Watt
Minimum Power Type
TGP
Maximum Power Consumption
100 Watt
Maximum Power Type
TGP
Supported Standards
DirectX
12_2
OpenGL
4.6
OpenCL
3.0
Vulkan
1.4
CUDA
12.0
Shader Model
6.9
Connectivity
Host Interface
PCIe 5.0 x16
