NVIDIA GeForce RTX 5090

NVIDIA GeForce RTX 5090

1 laptops with NVIDIA GeForce RTX 5090 in comparion

Core Information
GPU Name
GB203
GPU Variant
GN22-X11-A1
Model Series
NVIDIA GeForce RTX 50
Release Date
27.03.2025
GPU Specifications
GPU Architecture
Blackwell
Base Clock
990 MHz
Boost Clock
1515 MHz
Integrated GPU
No
MXM Module
No
Soldered
Yes
Compute Units
Render Output Units
112
Texture Mapping Units
328
Shader Units
10496
Tensor Cores
328
SM Count
82
Hardware Ray Tracing
Yes
Ray Tracing Units
82
Memory
Memory Type
GDDR7
Memory Clock
1750 MHz
Effective Memory Data Rate
28 Gbps
Memory Bandwidth
896 GB/s
System-Dependent Memory Bandwidth
No
Memory Size
24 GB
Memory Interface
256 Bit
Shared Memory
No
Dedicated Graphics Memory
Yes
Unified Memory
No
Cache
L2 Cache
64 MB
Theoretical Performance
Pixel Fill Rate
169.7 GPixel/s
Texture Fill Rate
496.9 GTexel/s
FP16 Compute Performance
31.8 TFLOPS
FP16 Ratio
1:1
FP32 Compute Performance
31.8 TFLOPS
FP64 Compute Performance
496.9 GFLOPS
FP64 Ratio
1:64
Manufacturing
Official Process Name
TSMC 4N
Foundry
TSMC
Process Node
5 nm
Chip Specifications
Die Area
378 mm²
Transistors
45600 Millionen
Transistor Density
120.6 M / mm²
Chip Integration
Monolithic
Power Consumption
Minimum Power Consumption
95 Watt
Minimum Power Type
TGP
Maximum Power Consumption
150 Watt
Maximum Power Type
TGP
Supported Standards
DirectX
12.2
OpenGL
4.6
OpenCL
3.0
Vulkan
1.4
CUDA
12.8
Shader Model
6.9
Connectivity
Host Interface
PCIe 5.0 x16
