NVIDIA GeForce MX550

NVIDIA GeForce MX550

3 laptops with NVIDIA GeForce MX550 in comparion

Core Information
GPU Name
TU117SB
GPU Variant
TU117-670-A1
Model Series
NVIDIA GeForce MX500
Release Date
17.12.2021
GPU Specifications
GPU Architecture
Turing
Base Clock
1065 MHz
Boost Clock
1320 MHz
Integrated GPU
No
MXM Module
No
Soldered
Yes
Compute Units
Render Output Units
16
Texture Mapping Units
32
Shader Units
1024
SM Count
16
Memory
Memory Type
GDDR6
Memory Clock
1500 MHz
Effective Memory Data Rate
12 Gbps
Memory Bandwidth
96 GB/s
System-Dependent Memory Bandwidth
No
Memory Size
2 GB
Memory Interface
64 Bit
Shared Memory
No
Dedicated Graphics Memory
Yes
Unified Memory
No
Cache
L2 Cache
2 MB
Theoretical Performance
Pixel Fill Rate
21.12 GPixel/s
Texture Fill Rate
42.24 GTexel/s
FP16 Compute Performance
2.703 TFLOPS
FP16 Ratio
1:1
FP32 Compute Performance
2.703 TFLOPS
FP64 Compute Performance
42.24 GFLOPS
FP64 Ratio
1:64
Manufacturing
Foundry
TSMC
Process Node
12 nm
Chip Specifications
Die Area
200 mm²
Transistors
4700 Millionen
Transistor Density
23.5 M / mm²
Power Consumption
Minimum Power Consumption
15 Watt
Maximum Power Consumption
25 Watt
Maximum Power Type
TDP
Supported Standards
DirectX
12_1
OpenGL
4.6
OpenCL
3.0
Vulkan
1.4
CUDA
7.5
Shader Model
6.9
Connectivity
Host Interface
PCIe 4.0 x8
